Product Details
Standard Features
■ Coupler: 2-5/16″ – 12.5K Ram w/ Hole Cover Plate
■ Tires: New ST225/75/R/15″ Radial Load Range “D” 8-Ply
■ Dove Tail: 4′ – For Easy Low To The Ground Loading
■ Safety Chains: 1/4″ Chain w/ Safety Latching Hooks
■ Wheels: 6- Hole Powder Coated Silver Mods
■ Stickers: Warnings & Safety/ DOT & Reflective Kearney Logos
■ Jack: 7K Sidewind Drop Leg W/ Sand Foot, Set In Center
■ Tie Downs: 3″ Stake Pockets(16′ & Smaller-10)(18’12)(20′-14) * Four- Weld On Top Of The Floor D-Rings
■Est Prepping: 2 Stage Degreasing And Acid Phosphate Wash W/ Rust- * Inhibitor To Ensure Maximum Paint Adhesion
■ Plug: 7 – Way Molded Plug Harness /Grounded To Frame
■ Ramps: 5′ Slide In Rolled Channel Iron W/ Holders
■ Exterior Finish: Painted With A Newly Inovated, Durable High Gloss * Acrylic Polyurethane Full Polyurethane Full Two-Component Finish
■ Lights: “LED” Running, Stop, Turn, and Clearance
■ Tongue: 20′ & Smaller 5″X3″X1/4″ Angle Iron Wrap Around * 22′ & Larger 5″X3″X 5/16″ Angle Iron Wrap Around
■ Undercoating: Completely Coated W/ A Durable Protective Finish
■ Fenders: 9″ x 72″ Tear Drop Smooth W/ Smooth Backing Plates
■ Frame: 6″ X 8.2# Channel Iron W/ Front Corners 45ed
■ Trim: Standard “White” Or “Black” Pin Striping* Chrome Gravel Gaurds On Front Of Fenders
■ Suspension: Equalizer W/ 5-Leave Eye-to-Eye Springs System
■Crossmembers: 3″ x 2″ x 3/16″ Angle Iron On 24″ Centers
■ Warranty: A Limited Two Year Kearney Guarantee
■ Axles: Two – 5.2K Axles Cambered & Accu-Lube Hubs
■ Bump Rails: 2-3/8″ Pipe Bump Rail / 8″ Tall
■ Brake: One rear -Electric Brake w/ Break Away & Charger
■ Floor: 1/8″ Steel Diamond Tread Plate Sheet Metal
