Product Details
EASY TO HANDLE AND EVEN EASIER TO OWN
Most mowers at this price are stamped from flimsy steel sheets and bolted together. Our MZ Series mowers are built side-by-side and up to the same tough manufacturing standards as our commercial mowers. So if you’re looking to step up to the efficiencies of zero-turn mowing, you won’t have to step down in build quality, power or performance. It’s our “too much fun to call it work” ride, and your “get back to having time” machine.
DOESN’T SKIMP ON COMFORT AND CONTROL
The cushioned seat adjusts front to back and steering is tighter and smoother with our steering dampening system for better response and maneuverability. The adjustable, left or right side deck lift pedal allows you to easily dial in a deck height for a perfect cut time and time again. The large capacity fuel tanks also allow for lots of deep storage and a cup holder. Easy access to all pulley and drive belts with the flip-up floorboard — with rubber mat — is a first for its class.
STANDARD FEATURES
Dual ZT-2200 EZT Integrated Drive Systems
Heavy-Gauge, All-Steel, All-Welded Frame
3/8˝ Steel Front Forks
7-Gauge All Steel, Formed and Welded Deck with Reinforced Edges
PEER, Maintenance-Free Spindles
Deck Lift Pedal with Deck Dial Adjustment
Seat Lifts for Easy Maintenance and Cleaning
Electric PTO
Comfort Seat
MZ MAGNUM ENGINE OPTIONS
Kohler. 4800 – 725cc, 22hp Air-Cooled 7000 KT725
Kohler. 5400 – 725cc, 25hp Air-Cooled 7000 KT740
Kawasaki. 4800/5400 – 726cc, 22hp Air-Cooled FR651
MZ MAGNUM DIMENSIONS
Cutting Widths. 4800 – 48″; 5400 – 54″
Weight. 4800 – 659 lbs.; 5400 – 687 lbs.
Overall Height / Length. 42″/76″
Chute Up / Chute Down Width. 4800 – 54″/61″; 5400 – 58″/67″
MZ MAGNUM FEATURES
Transmission. ZT-2200 EZT Integrated Unit
Deck Thickness. 3/16″ Thick Solid Steel
Cutting Height 1.5″ – 4.5″ with Deck Height Control System
Lift & Height Adjustment. Foot-Assist Manual Lift with Dial-Style Height Adjustment. Optional Electric Lift.
Rear Tires / Front Tires. 18×9.5-8 Turf / 11×6-5 Smooth
Fuel. 5 Gallons, Unleaded Gasoline
Ground Speed (Forward). Up To 6 mph
